10G SFP+ CWDM, Single Mode, 10KM~100KM 光纖模組

FSPP-H7-Cxx-xxD

Product Features

10G SFP+ CWDM Transceiver
Hot Pluggable, Duplex LC, CWDM DFB / EML, Single Mode, 10KM~100KM

Compliant with 10GBASE
Compliant with CPRI Option 7, 8
Compliant with SFF-8431, SFF-8432 SFP+ MSA
Support 8.5Gb/s to 11.32Gb/s Multi-Rate
Hot Pluggable
APD receiver
CWDM DFB/EML laser transmitter
Duplex LC connector
Single +3.3V power supply
2-wire interface for management and diagnostic monitor compliant with SFF-8472
Link distance 10km~100km over SM fiber
RoHS Compliant

Product Application

10GBase-X Ethernet
1200-SM-LL-L 10GFiber Channel
10G CWDM Networks
SONET OC-192 & SDH STM-64 @9.953Gbps

Standard SPEC :

PS. Please contact our Sales for Customized SPEC

Part Number	Data Rate	Distance	Wavelength	Temperature	Remark
FSPP-H7-Cxx-10D	10Gbps	SM 10m (8dB)	CWDM DFB 1270nm~1570nm	0~70°C	SFP+ 10G-CWDMxx-10km(xx = 27~57)
FSPP-H7-Cxx-20D	10Gbps	SM 20km (12dB)	CWDM DFB 1270nm~1450nm	0~70°C	SFP+ 10G-CWDMxx-20km(xx = 27~45)
FSPP-H7-Cxx-40D	10Gbps	SM 40km (16dB)	CWDM DFB 1350nm~1450nm	0~70°C	SFP+ 10G-CWDMxx-40km(xx = 35~45) *Can not guaranteed to reach 40km
FSPP-H7-Cxx-40D	10Gbps	SM 40km (16dB)	CWDM EML 1470nm~1610nm	0~70°C	SFP+ 10G-CWDMxx-40km(xx = 47~61)
FSPP-H7-Cxx-40Di	10Gbps	SM 40km (16dB)	CWDM EML 1470nm~1610nm	-40~85°C	SFP+ 10G-CWDMxx-40km(xx = 47~61), I-Temp
FSPP-H7-Cxx-40DM	10Gbps	SM 40km (16dB)	CWDM EML 1470nm~1610nm	0~70°C	SFP+ 10G-CWDMxx-40km(xx = 47~61), Multi-Rate
FSPP-H7-Cxx-40DMi	10Gbps	SM 40km (16dB)	CWDM EML 1470nm~1610nm	-40~85°C	SFP+ 10G-CWDMxx-40km (xx = 47~61), Multi-Rate, I-Temp
FSPP-H7-Cxx-60D	10Gbps	SM 60km (23dB)	CWDM DFB 1270nm~1330nm	0~70°C	SFP+ 10G-CWDMxx-60km(xx = 27~33)
FSPP-H7-Cxx-80D	10Gbps	SM 80km (23dB)	CWDM EML 1470nm~1610nm	0~70°C	SFP+ 10G-CWDMxx-80km(xx = 47~61)
FSPP-H7-Cxx-80Di	10Gbps	SM 80km (23dB)	CWDM EML 1470nm~1610nm	-40~85°C	SFP+ 10G-CWDMxx-80km(xx = 47~61), I-Temp
FSPP-H7-Cxx-A0D	10Gbps	SM 100km (26dB)	CWDM EML 1470nm~1610nm	0~70°C	SFP+ 10G-CWDMxx-100km(xx = 47~61)
FSPP-H7-Cxx-b08D	10Gbps	SM 10km (8dB)	CWDM DFB 1270nm~1610nm	0~70°C	SFP+ 10G-CWDMxx-8dB(10km)(xx = 27~61)
FSPP-H7-Cxx-b08Di	10Gbps	SM 10km (8dB)	CWDM DFB 1270nm~1610nm	-40~85°C	SFP+ 10G-CWDMxx-8dB(10km)(xx = 27~61), I-Temp
FSPP-H7-Cxx-b12D	10Gbps	SM 20km (12dB)	CWDM DFB 1270nm~1450nm	0~70°C	SFP+ 10G-CWDMxx-12dB(20km)(xx = 27~45)
FSPP-H7-Cxx-b12Di	10Gbps	SM 20km (12dB)	CWDM DFB 1270nm~1450nm	-40~85°C	SFP+ 10G-CWDMxx-12dB(20km)(xx = 27~45), I-Temp
FSPP-H7-Cxx-b26D	10Gbps	100km (26dB)	CWDM DFB 1270nm~1450nm	0~70°C	SFP+ 10G-CWDMxx-26dB(100km)(xx = 47~61)
FSPP-H7-Cxx-b26Di	10Gbps	100km (26dB)	CWDM DFB 1270nm~1450nm	-40~85°C	SFP+ 10G-CWDMxx-26dB(100km)(xx = 47~61), I-Temp

*Please contact our Sales for Industrial Temperature Transceiver.
*Please tell us what brand and model name of Host equipment you will apply. We need to know what coding to be input for you.

FAQ

1. Do you have any MOQ?

Ans : No, we did not set any MOQ unless for Special promotion item.

2. How can I pay you?

Ans : We accept Bank Wire Transfer, Paypal ( for <$1000 payment )

Please contact us for our Paypay account.

3. What is your warranty?

Ans : We offer basic 1 year warranty for all products.

4. Can I use your Transceiver module on Cisco or Alcatel-Lucent equipment?

Ans : Yes, we can offer Transceiver modules compatible on Cisco, Alcatel-Lucent, HP, Extreme…etc.

5. How about your lead-time?

Ans : For normal order, we can deliver in 1~2 weeks, for Hot selling products, we can deliver within 3 days.
